Въглероден филтър
Чиста и ефективна екстракция на въздуха благодарение на интегрираните въглеродни филтри. (* въглеродният филтър се продава отделно).
Въглероден филтър
електронен дисплей
Осветление: халогенно
Accessories Pipe | Air flaps Yes | Delay Yes |
Maximum time of delay 15 ' | Montage template Yes | Panel - language version Pictograms |
Protection class of electric shock I_Class | Type of work Extraction/Recirculation |
Carbon filter(s) included Yes | Number of carbon filters 1 | Number of grease filters 2 |
Number of layers in grease filter 5 | Number of speed 3 | Type of control Soft touch |
Type of display LCD | Type of grease filters Aluminium frame | Carbon filter type FWP 03 |
Air flow at 1 speed - extractor by EN 61591 430 m3/h | Air flow at 2 speed - extractor by EN 61591 540 m3/h | Air flow at 3 speed - extractor by EN 61591 642 m3/h | |||||||||||||||||||||||||||||
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 642 m3/h | Air Flow at Minimum Speed in Normal Use 430 m3/h | Air Flow Rate at Best Efficiency Point - Q BEP 396 m3/h | |||||||||||||||||||||||||||||
Air Pressure at Best Efficiency Point P BEP 340.5 Pa | Річне споживання електроенергії 78 kWh | Average Illumination of the Lighting System on the Cooking Surface - E middle 87 lux | |||||||||||||||||||||||||||||
Container qty 40'HQ 441 | Control panel on one side/two sides One side | Country of Origin on Rating Label Made in PRC | |||||||||||||||||||||||||||||
Dimensions of grease filter 340 x 260,2 mm | Display color Red | Distance from light cover to wall 385 mm | |||||||||||||||||||||||||||||
Distance to electric hob 450 mm | Distance to gas hob 650 mm | Electric Power Input at Best Efficiency Point - W BEP 173.1 W | |||||||||||||||||||||||||||||
Гідродинамічна ефективність 21.6 | Гідродинамічна ефективність C | Grease Filtering Efficiency - GFE hood 82.5 % | |||||||||||||||||||||||||||||
Ефективність фільтрації жирів C | Internal/external motor Internal | Main lighting colour temperature [K] 6500 | Потужність освітлення 29 lux/W | Потужність освітлення A | клас ефективності освітлення A | Maximum Possible Air Flow 642 m3/h | Motor unit rated power 230 W | Motor type/model E series | Net depth 500 mm | Net height max 950 mm | Net height min 570 mm | вага нетто 13.1 kg | Net width 600 mm | рівень шуму 57 dB | рівень шуму 63 dB | рівень шуму 68 dB | Nominal Power of the Lighting System - W L 3 W | Number of motor units 1 | Number units of main lighting 2 | Діаметр отвору для виведення повітря 150 mm | Type of plug or cable Euro plug | Power Consumption in Standby Mode - Ps 0.53 W | Довжина проводу живлення 120 cm | Power rating 234 W | Напруга живлення 230V | Power unit of main lighting 2 W | Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 68 dB | Sound Power Emission at Minimum Speed Available in Normal Use 57 dB | рівень шуму 68 dB | Time Increase Factor - f 1.2 | Type of main lighting LED - other |
Чиста и ефективна екстракция на въздуха благодарение на интегрираните въглеродни филтри. (* въглеродният филтър се продава отделно).
Нашите абсорбатори са оборудвани с халогенно осветление. Във всички модели включването на осветлението е независимо от действието на абсорбатора. Резултатът е удобство за потребителя.
