Accessories - | Air flaps Yes | Panel - language version Pictograms |
Protection class of electric shock I_Class | Type of work Extraction/Recirculation |
Number of carbon filters 2 | Number of grease filters 1 | Number of layers in grease filter 5 |
Number of speed 3 | Type of control Push buttons | Type of grease filters Aluminium frame |
Carbon filter type KF 17154 |
Frequency 50 | Air flow at 1 speed - extractor by EN 61591 232 m3/h | Air flow at 2 speed - extractor by EN 61591 312 m3/h | |||||||||||||||||||||||||||||
Air flow at 3 speed - extractor by EN 61591 389 m3/h | Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 389 m3/h | Air Flow at Minimum Speed in Normal Use 232 m3/h | |||||||||||||||||||||||||||||
Air Flow Rate at Best Efficiency Point - Q BEP 227.6 m3/h | Air Pressure at Best Efficiency Point P BEP 185.1 Pa | Annual energy consumption 46.6 kWh | |||||||||||||||||||||||||||||
Average Illumination of the Lighting System on the Cooking Surface - E middle 92.3 lux | Container qty 40'HQ 1125 | Control panel on one side/two sides One side | |||||||||||||||||||||||||||||
Country of Origin on Rating Label Made in PRC | Dimensions of grease filter 492 x 162.5 mm black | Display color No | |||||||||||||||||||||||||||||
Distance from light cover to wall 63 mm | Distance to electric hob 450 mm | Distance to gas hob 650 mm | |||||||||||||||||||||||||||||
Electric Power Input at Best Efficiency Point - W BEP 81.2 W | Fluid Dynamic Efficiency - FDE hood 14.4 | Fluid Dynamic Efficiency Class D | |||||||||||||||||||||||||||||
Grease Filtering Efficiency - GFE hood 80 % | Grease Filtering Efficiency Class C | Internal/external motor Internal | Main lighting colour temperature [K] 6500 | Lighting Efficiency - LE hood 30.8 lux/W | Lighting Efficiency Class A | Lighting Efficiency Class A | Maximum Possible Air Flow 389 m3/h | Motor unit rated power 120 W | Motor type/model F series | Net depth 290 mm | Net height max 176 mm | Net height min 176 mm | Net weight 5.5 kg | Net width 550 mm | Noise level at 1 speed - extractor by EN 60704-2-13 58 dB | Noise level at 2 speed - extractor by EN 60704-2-13 63 dB | Noise level at 3 speed - extractor by EN 60704-2-13 65 dB | Nominal Power of the Lighting System - W L 3 W | Number of motor units 1 | Number units of main lighting 1 | Air exhaust diameter 120 mm | Type of plug or cable Euro plug | Power cabel length 120 cm | Power rating 125 W | Power Supply Voltage 230V | Power unit of main lighting 5 W | Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 65 dB | Sound Power Emission at Minimum Speed Available in Normal Use 58 dB | Noise level 65 dB | Time Increase Factor - f 1.5 | Type of main lighting LED strip |
